NTPsec

Dell-2018

Report generated: Sat May 23 04:53:05 2026 UTC
Start Time: Fri May 22 04:53:05 2026 UTC
End Time: Sat May 23 04:53:05 2026 UTC
Report Period: 1.0 days

Stats for the last 1, 7, 35, 98, 371, some days, or live gps data.

Local Clock Time/Frequency Offsets

local offset plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Time Offset -602.926 -431.754 -326.294 -14.221 326.601 456.501 591.912 652.895 888.255 203.260 -13.472 µs 0.1236 2.584
Local Clock Frequency Offset 11.239 11.244 11.253 11.399 11.591 11.616 11.624 0.338 0.372 0.113 11.420 ppm 0.176 1.66

The time and frequency offsets between the ntpd calculated time and the local system clock. Showing frequency offset (red, in parts per million, scale on right) and the time offset (blue, in μs, scale on left). Quick changes in time offset will lead to larger frequency offsets.

These are fields 3 (time) and 4 (frequency) from the loopstats log file.



Local RMS Time Jitter

local jitter plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local RMS Time Jitter 223.515 241.609 264.283 335.196 425.900 463.707 516.748 161.617 222.098 49.875 337.568 µs 0.4149 2.961

The RMS Jitter of the local clock offset. In other words, how fast the local clock offset is changing.

Lower is better. An ideal system would be a horizontal line at 0μs.

RMS jitter is field 5 in the loopstats log file.



Local RMS Frequency Jitter

local stability plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local RMS Frequency Jitter 4.470 4.724 4.955 6.079 7.548 8.119 9.182 2.593 3.395 0.790 6.146 ppb 0.4507 2.915

The RMS Frequency Jitter (aka wander) of the local clock's frequency. In other words, how fast the local clock changes frequency.

Lower is better. An ideal clock would be a horizontal line at 0ppm.

RMS Frequency Jitter is field 6 in the loopstats log file.



Local Clock Time Offset Histogram

local offset histogram plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Offset -602.926 -431.754 -326.294 -14.221 326.601 456.501 591.912 652.895 888.255 203.260 -13.472 µs 0.1236 2.584

The clock offsets of the local clock as a histogram.

The Local Clock Offset is field 3 from the loopstats log file.



Local Temperatures

local temps plot

Local temperatures. These will be site-specific depending upon what temperature sensors you collect data from. Temperature changes affect the local clock crystal frequency and stability. The math of how temperature changes frequency is complex, and also depends on crystal aging. So there is no easy way to correct for it in software. This is the single most important component of frequency drift.

The Local Temperatures are from field 3 from the tempstats log file.



Local Frequency/Temp

local freq temps plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Frequency Offset 11.239 11.244 11.253 11.399 11.591 11.616 11.624 0.338 0.372 0.113 11.420 ppm 0.176 1.66
Temp /dev/sda 20.000 20.000 20.000 25.000 26.000 28.000 28.000 6.000 8.000 2.222 24.500 °C
Temp LM0 36.000 36.000 37.000 39.000 42.000 58.000 58.000 5.000 22.000 2.993 39.042 °C
Temp LM1 31.000 31.000 31.000 32.000 33.000 34.000 34.000 2.000 3.000 0.671 32.198 °C
Temp LM2 34.000 34.000 35.000 36.000 37.000 38.000 38.000 2.000 4.000 0.593 35.885 °C
Temp LM3 38.000 38.000 39.000 39.000 40.000 41.000 41.000 1.000 3.000 0.542 39.365 °C
Temp LM4 0.000 0.000 0.000 0.000 0.000 0.000 0.000 0.000 0.000 0.000 0.000 °C
Temp LM5 38.000 38.000 38.000 38.000 38.000 38.000 38.000 0.000 0.000 0.000 38.000 °C
Temp LM6 33.000 33.000 34.000 35.000 35.000 37.000 37.000 1.000 4.000 0.656 34.667 °C
Temp LM7 35.000 35.000 35.000 37.000 38.000 40.000 40.000 3.000 5.000 0.841 36.542 °C
Temp LM8 35.000 35.000 35.000 37.000 38.000 40.000 40.000 3.000 5.000 0.870 36.615 °C
Temp LM9 35.000 35.000 35.000 37.000 38.000 40.000 40.000 3.000 5.000 0.870 36.615 °C
Temp ZONE0 20.000 20.000 20.000 20.000 20.000 20.000 20.000 0.000 0.000 0.000 20.000 °C
Temp ZONE1 34.000 34.000 35.000 36.000 37.000 38.000 38.000 2.000 4.000 0.593 35.885 °C
Temp ZONE2 38.000 38.000 38.000 38.000 38.000 38.000 38.000 0.000 0.000 0.000 38.000 °C
Temp ZONE3 34.000 34.000 35.000 36.000 37.000 38.000 38.000 2.000 4.000 0.603 35.896 °C
Temp ZONE4 34.000 34.000 35.000 36.000 37.000 38.000 38.000 2.000 4.000 0.593 35.885 °C
Temp ZONE5 36.000 36.000 37.000 39.000 42.000 57.000 57.000 5.000 21.000 2.931 39.052 °C
Temp ZONE6 31.000 31.000 31.000 32.000 33.000 34.000 34.000 2.000 3.000 0.677 32.177 °C

The frequency offsets and temperatures. Showing frequency offset (red, in parts per million, scale on right) and the temperatures.

These are field 4 (frequency) from the loopstats log file, and field 3 from the tempstats log file.



Local GPS

local gps plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
nSats 10.000 10.000 10.000 14.000 17.000 17.000 17.000 7.000 7.000 1.873 13.771 nSat -0.1888 2.207
TDOP 0.550 0.550 0.580 0.770 1.220 1.770 1.770 0.640 1.220 0.211 0.806 2.044 8.348

Local GPS. The Time Dilution of Precision (TDOP) is plotted in blue. The number of visible satellites (nSat) is plotted in red.

TDOP is field 3, and nSats is field 4, from the gpsd log file. The gpsd log file is created by the ntploggps program.

TDOP is a dimensionless error factor. Smaller numbers are better. TDOP ranges from 1 (ideal), 2 to 5 (good), to greater than 20 (poor). Some GNSS receivers report TDOP less than one which is theoretically impossible.



Server Offsets

peer offsets plot

The offset of all refclocks and servers. This can be useful to see if offset changes are happening in a single clock or all clocks together.

Clock Offset is field 5 in the peerstats log file.



Server Offset 108.61.215.221

peer offset 108.61.215.221 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 108.61.215.221 0.783 0.783 1.627 4.261 5.676 6.235 6.235 4.050 5.452 1.057 4.175 ms -0.9987 4.628

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 139.84.137.244

peer offset 139.84.137.244 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 139.84.137.244 11.453 11.453 14.201 16.681 23.381 24.033 24.033 9.181 12.580 2.745 17.591 ms 0.6285 3.023

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 194.0.5.123

peer offset 194.0.5.123 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 194.0.5.123 2.258 2.360 3.186 4.981 7.401 8.078 8.469 4.215 5.718 1.261 4.993 ms 0.3169 2.78

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 23.142.248.8

peer offset 23.142.248.8 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 23.142.248.8 8.961 8.961 9.481 11.034 12.934 13.292 13.292 3.453 4.331 0.957 11.153 ms 0.1621 2.729

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 23.186.168.123

peer offset 23.186.168.123 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 23.186.168.123 -2.188 -1.934 -0.225 2.365 3.923 4.563 5.399 4.148 6.497 1.196 2.288 ms -0.8338 4.878

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 23.186.168.125

peer offset 23.186.168.125 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 23.186.168.125 -3.838 -0.658 0.534 2.364 4.235 5.071 5.555 3.701 5.729 1.241 2.400 ms -0.8661 6.527

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 67.217.246.204

peer offset 67.217.246.204 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 67.217.246.204 -33.203 -33.203 -9.448 -3.923 -2.096 5.500 5.500 7.352 38.703 4.396 -4.515 ms -4.612 30.57

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Refclock Offset SHM(0)

peer offset SHM(0) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Refclock Offset SHM(0) -153.630 -151.278 -149.065 -140.455 -133.929 -131.919 -130.179 15.136 19.359 4.632 -140.877 ms -0.3014 2.402

The offset of a local refclock in seconds. This is useful to see how the measured offset is behaving.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local serial GPS 200 ms; local PPS 20µs.

Clock Offset is field 5 in the peerstats log file.



Refclock Offset SHM(1)

peer offset SHM(1) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Refclock Offset SHM(1) -754.870 -578.641 -512.685 -145.381 179.213 307.143 413.593 691.898 885.784 210.195 -170.217 µs 0.0217 2.438

The offset of a local refclock in seconds. This is useful to see how the measured offset is behaving.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local serial GPS 200 ms; local PPS 20µs.

Clock Offset is field 5 in the peerstats log file.



Server Jitters

peer jitters plot

The RMS Jitter of all refclocks and servers. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 108.61.215.221

peer jitter 108.61.215.221 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 108.61.215.221 0.714 0.714 1.110 2.116 8.997 19.344 19.344 7.887 18.630 3.317 3.277 ms 3.189 14.47

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 139.84.137.244

peer jitter 139.84.137.244 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 139.84.137.244 2.161 2.161 2.436 22.366 29.032 30.174 30.174 26.596 28.014 7.877 19.913 ms -1.02 3.024

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 194.0.5.123

peer jitter 194.0.5.123 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 194.0.5.123 0.556 0.912 1.078 2.472 9.439 14.094 14.949 8.362 13.181 2.426 3.125 ms 2.738 11.41

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 23.142.248.8

peer jitter 23.142.248.8 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 23.142.248.8 0.648 0.648 0.997 2.720 14.976 18.093 18.093 13.979 17.445 4.592 5.131 ms 1.097 3.013

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 23.186.168.123

peer jitter 23.186.168.123 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 23.186.168.123 0.827 0.887 1.097 2.672 15.883 22.582 26.195 14.786 21.695 4.547 3.933 ms 3.062 12.07

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 23.186.168.125

peer jitter 23.186.168.125 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 23.186.168.125 0.412 0.469 1.033 2.615 17.480 29.174 32.817 16.446 28.705 5.217 4.068 ms 3.612 16.49

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 67.217.246.204

peer jitter 67.217.246.204 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 67.217.246.204 0.000 0.000 3.368 16.630 25.555 30.078 30.078 22.187 30.078 7.192 15.430 ms -0.2535 2.272

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Refclock RMS Jitter SHM(0)

peer jitter SHM(0) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Refclock RMS Jitter SHM(0) 0.440 0.616 0.908 2.328 5.547 7.258 8.554 4.640 6.643 1.461 2.650 ms 1.073 3.915

The RMS Jitter of a local refclock. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Refclock RMS Jitter SHM(1)

peer jitter SHM(1) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Refclock RMS Jitter SHM(1) 113.696 140.948 169.755 263.526 459.024 533.820 609.044 289.269 392.872 86.757 280.471 µs 0.9034 3.6

The RMS Jitter of a local refclock. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Summary


Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Frequency Offset 11.239 11.244 11.253 11.399 11.591 11.616 11.624 0.338 0.372 0.113 11.420 ppm 0.176 1.66
Local Clock Time Offset -602.926 -431.754 -326.294 -14.221 326.601 456.501 591.912 652.895 888.255 203.260 -13.472 µs 0.1236 2.584
Local RMS Frequency Jitter 4.470 4.724 4.955 6.079 7.548 8.119 9.182 2.593 3.395 0.790 6.146 ppb 0.4507 2.915
Local RMS Time Jitter 223.515 241.609 264.283 335.196 425.900 463.707 516.748 161.617 222.098 49.875 337.568 µs 0.4149 2.961
Refclock Offset SHM(0) -153.630 -151.278 -149.065 -140.455 -133.929 -131.919 -130.179 15.136 19.359 4.632 -140.877 ms -0.3014 2.402
Refclock Offset SHM(1) -754.870 -578.641 -512.685 -145.381 179.213 307.143 413.593 691.898 885.784 210.195 -170.217 µs 0.0217 2.438
Refclock RMS Jitter SHM(0) 0.440 0.616 0.908 2.328 5.547 7.258 8.554 4.640 6.643 1.461 2.650 ms 1.073 3.915
Refclock RMS Jitter SHM(1) 113.696 140.948 169.755 263.526 459.024 533.820 609.044 289.269 392.872 86.757 280.471 µs 0.9034 3.6
Server Jitter 108.61.215.221 0.714 0.714 1.110 2.116 8.997 19.344 19.344 7.887 18.630 3.317 3.277 ms 3.189 14.47
Server Jitter 139.84.137.244 2.161 2.161 2.436 22.366 29.032 30.174 30.174 26.596 28.014 7.877 19.913 ms -1.02 3.024
Server Jitter 194.0.5.123 0.556 0.912 1.078 2.472 9.439 14.094 14.949 8.362 13.181 2.426 3.125 ms 2.738 11.41
Server Jitter 23.142.248.8 0.648 0.648 0.997 2.720 14.976 18.093 18.093 13.979 17.445 4.592 5.131 ms 1.097 3.013
Server Jitter 23.186.168.123 0.827 0.887 1.097 2.672 15.883 22.582 26.195 14.786 21.695 4.547 3.933 ms 3.062 12.07
Server Jitter 23.186.168.125 0.412 0.469 1.033 2.615 17.480 29.174 32.817 16.446 28.705 5.217 4.068 ms 3.612 16.49
Server Jitter 67.217.246.204 0.000 0.000 3.368 16.630 25.555 30.078 30.078 22.187 30.078 7.192 15.430 ms -0.2535 2.272
Server Offset 108.61.215.221 0.783 0.783 1.627 4.261 5.676 6.235 6.235 4.050 5.452 1.057 4.175 ms -0.9987 4.628
Server Offset 139.84.137.244 11.453 11.453 14.201 16.681 23.381 24.033 24.033 9.181 12.580 2.745 17.591 ms 0.6285 3.023
Server Offset 194.0.5.123 2.258 2.360 3.186 4.981 7.401 8.078 8.469 4.215 5.718 1.261 4.993 ms 0.3169 2.78
Server Offset 23.142.248.8 8.961 8.961 9.481 11.034 12.934 13.292 13.292 3.453 4.331 0.957 11.153 ms 0.1621 2.729
Server Offset 23.186.168.123 -2.188 -1.934 -0.225 2.365 3.923 4.563 5.399 4.148 6.497 1.196 2.288 ms -0.8338 4.878
Server Offset 23.186.168.125 -3.838 -0.658 0.534 2.364 4.235 5.071 5.555 3.701 5.729 1.241 2.400 ms -0.8661 6.527
Server Offset 67.217.246.204 -33.203 -33.203 -9.448 -3.923 -2.096 5.500 5.500 7.352 38.703 4.396 -4.515 ms -4.612 30.57
TDOP 0.550 0.550 0.580 0.770 1.220 1.770 1.770 0.640 1.220 0.211 0.806 2.044 8.348
Temp /dev/sda 20.000 20.000 20.000 25.000 26.000 28.000 28.000 6.000 8.000 2.222 24.500 °C
Temp LM0 36.000 36.000 37.000 39.000 42.000 58.000 58.000 5.000 22.000 2.993 39.042 °C
Temp LM1 31.000 31.000 31.000 32.000 33.000 34.000 34.000 2.000 3.000 0.671 32.198 °C
Temp LM2 34.000 34.000 35.000 36.000 37.000 38.000 38.000 2.000 4.000 0.593 35.885 °C
Temp LM3 38.000 38.000 39.000 39.000 40.000 41.000 41.000 1.000 3.000 0.542 39.365 °C
Temp LM4 0.000 0.000 0.000 0.000 0.000 0.000 0.000 0.000 0.000 0.000 0.000 °C
Temp LM5 38.000 38.000 38.000 38.000 38.000 38.000 38.000 0.000 0.000 0.000 38.000 °C
Temp LM6 33.000 33.000 34.000 35.000 35.000 37.000 37.000 1.000 4.000 0.656 34.667 °C
Temp LM7 35.000 35.000 35.000 37.000 38.000 40.000 40.000 3.000 5.000 0.841 36.542 °C
Temp LM8 35.000 35.000 35.000 37.000 38.000 40.000 40.000 3.000 5.000 0.870 36.615 °C
Temp LM9 35.000 35.000 35.000 37.000 38.000 40.000 40.000 3.000 5.000 0.870 36.615 °C
Temp ZONE0 20.000 20.000 20.000 20.000 20.000 20.000 20.000 0.000 0.000 0.000 20.000 °C
Temp ZONE1 34.000 34.000 35.000 36.000 37.000 38.000 38.000 2.000 4.000 0.593 35.885 °C
Temp ZONE2 38.000 38.000 38.000 38.000 38.000 38.000 38.000 0.000 0.000 0.000 38.000 °C
Temp ZONE3 34.000 34.000 35.000 36.000 37.000 38.000 38.000 2.000 4.000 0.603 35.896 °C
Temp ZONE4 34.000 34.000 35.000 36.000 37.000 38.000 38.000 2.000 4.000 0.593 35.885 °C
Temp ZONE5 36.000 36.000 37.000 39.000 42.000 57.000 57.000 5.000 21.000 2.931 39.052 °C
Temp ZONE6 31.000 31.000 31.000 32.000 33.000 34.000 34.000 2.000 3.000 0.677 32.177 °C
nSats 10.000 10.000 10.000 14.000 17.000 17.000 17.000 7.000 7.000 1.873 13.771 nSat -0.1888 2.207
Summary as CSV file

Stats for the last 1, 7, 35, 98, 371, some days, or live gps data.

Glossary:

frequency offset:
The difference between the ntpd calculated frequency and the local system clock frequency (usually in parts per million, ppm)
jitter, dispersion:
The short term change in a value. NTP measures Local Time Jitter, Refclock Jitter, and Server Jitter in seconds. Local Frequency Jitter is in ppm or ppb.
ms, millisecond:
One thousandth of a second = 0.001 seconds, 1e-3 seconds
mu, mean:
The arithmetic mean: the sum of all the values divided by the number of values. The formula for mu is: "mu = (∑xi) / N". Where xi denotes the data points and N is the number of data points.
ns, nanosecond:
One billionth of a second, also one thousandth of a microsecond, 0.000000001 seconds and 1e-9 seconds.
percentile:
The value below which a given percentage of values fall.
ppb, parts per billion:
Ratio between two values. These following are all the same: 1 ppb, one in one billion, 1/1,000,000,000, 0.000,000,001, 1e-9 and 0.000,000,1%
ppm, parts per million:
Ratio between two values. These following are all the same: 1 ppm, one in one million, 1/1,000,000, 0.000,001, and 0.000,1%
‰, parts per thousand:
Ratio between two values. These following are all the same: 1 ‰. one in one thousand, 1/1,000, 0.001, and 0.1%
refclock:
Reference clock, a local GPS module or other local source of time.
remote clock:
Any clock reached over the network, LAN or WAN. Also called a peer or server.
time offset:
The difference between the ntpd calculated time and the local system clock's time. Also called phase offset.
σ, sigma:
Sigma denotes the standard deviation (SD) and is centered on the arithmetic mean of the data set. The SD is simply the square root of the variance of the data set. Two sigma is simply twice the standard deviation. Three sigma is three times sigma. Smaller is better.
The formula for sigma is: "σ = √[ ∑(xi-mu)^2 / N ]". Where xi denotes the data points and N is the number of data points.
Skewness, Skew:
The skewness of a random variable X is the third standardized moment and is a dimension-less ratio. ntpviz uses the FIsher-Pearson moment of skewness. There are other different ways to calculate Skewness Wikipedia describes Skewness best: "The qualitative interpretation of the skew is complicated and unintuitive."
A normal distribution has a skewness of zero.
Kurtosis, Kurt:
The kurtosis of a random variable X is the fourth standardized moment and is a dimension-less ratio. ntpviz uses standard Kurtosis. There are other different ways to calculate Kurtosis.
A normal distribution has a Kurtosis of three. NIST describes a kurtosis over three as "heavy tailed" and one under three as "light tailed".
upstream clock:
Any server or reference clock used as a source of time.
µs, us, microsecond:
One millionth of a second, also one thousandth of a millisecond, 0.000,001 seconds, and 1e-6 seconds.



This page autogenerated by ntpviz, part of the NTPsec project
html 5    Valid CSS!
